Hobbywing Quicrun 1060 Waterproof Brushed ESC (2-3S)

Model / SKU
QUICRUN-WP-1060 BRUSHED  / 30120201
Fwd Cont. Current /Peak Current/ Resistance
60A/360A/0.001Ω
Rev Cont. Current /Peak Current/ Resistance 30A/180A/0.002Ω
Motor Type Supported Brushed Motor
Car Applicable 1:10 Touring Car, Buggy, Short Course Truck, Monster, Truggy, Rock Crawler and Tank
Suitable Battery
Brushed Motor Limit
For 2S LiPo or 6 cell NiMH:
540 or 550 Size Motor: ≥12T,
Or RPM<30000 @7.2V

For 3S LiPo or 9 cell NiMH:
540 or 550 Size Motor: ≥18T
Or RPM< 20000 @7.2V

BEC Output 2A/5V (Switch Mode)
PWM Frequency 1KHz
Size/ Weight 35.5(L)*32.18(W)*18(H) / 39g
Running Modes Forward/Reverse/Brake, Forward/Brake, Forward/Reverse
Cooling Fan No need

In Stock

Description

Water-proof and dust-proof for all-weather races & boat application
  • Water-proof and dust-proof, suitable for all weather races.
  • Small size, with built-in capacitor module.
  • Fwd/Rev/Br running mode fits various vehicles (Fwd =Forward, Br=Brake, Rev=Reverse).
  • Great current endurance capability.
  • Great built-in BEC output capacity.
  • Automatic throttle range calibration, easy to use.
  • ESC parameters are easy to set with jumpers.
  • Multiple protections:
    • Over Voltage Protection
    • Low voltage cut-off protection for battery
    • Over-heating protection
    • Throttle signal loss protection.
